Home > Automatic Rotary Bag Filling and Sealing Machinery
XFG-300 Automatic Premade Doypack Pouch Filling And Sealing Machine

I. Main Capacity and Application: Automatic Premade Pouch Filling And Sealing Machine is used for the flat bag, standup bag、 bag with zipper, and the machine can fill and seal different granule, powder and the liquid products by matching with different measuring system.
II. Character: While the bag size is different, it is easy to operate the machine by using the handle to adjust the width of the bag-nipping claw.

Application of the Premade Pouch Filling And Sealing Machine
5. Powder type: wheat flour, milk powder, powder of lotus root, powder of flavoring, spices,juice powder, soup powder, medicine, and additive, etc.
6. Granules: chicken essence, monosodium glutamate, salt, sugar, seed, fertilizer, fish seed, pesticide, chemical powder, etc.
7. Solid: fruit chips, confectionary, snack, nuts, rice cracker, biscuit, cake, candy, peanuts, wing of the chicken, ball and frozen dumpling, etc.
8. Liquid: sauce, oil, jam, salad jam, juice, beverage, shampoo, liquid detergent, etc.
Two or three materials filling: curry, instant dumpling and tinned food, etc.
Technical Parameter

包装能力 Capacity

30-40 bag/min,
according to product type and characteristics

袋子尺寸 Bag Size

(L)150-350mm (W)150-220 mm

包装重量 Filling weight

Up to1000 g/bag (max)

封口方式 Bag sealing

热封 Sealing by heat and pressure

电源 Power supply

AC380V±10%,3-phase 50Hz

使用功率 Power Consumption

2.0KW

压缩空气 Air Consumption

0.2m3/min at 5-8 kgf/cm2
压缩空气由客户提供
Air compressor is supplied by customer

机器重量 Machine Weight

1200kg

机器尺寸 Dimension

W×L×H 1340×1895×1435mm
